Yamaha Motorcycles


XT600E 1999
Engine
Configuration Air cooled 4-stroke single cylinder SOHC 4 valves. Nicalsil bore. Gearbox 5 Speed
Bore & Stroke 95x84 mm (3.74x3.31 in) Ignition T.C.I. (digital)
Capacity 595 ccm Charging system 12v
Compression Ratio 8.5:1 Starter Electric
Max Power 43PS(32,2kW)@6500rpm Transmission 45/15
Max Torque 4,9kg-m(48,1Nm)@5500rpm Clutch Wet multiplate
Fuel TK Y26PV Lubrication Dry sump, SAE 20W40 type SE,
2.5L (2.1 Imp qt, 2.5 US qt)
Chassis
Frame 27.75° caster, 120mm trail Wheels
Dimensions
Weight
Wheelbase
Length
Seat Height
 Ground Clearance

156.0 kg
1,440 mm
2,220 mm
855 mm
230 mm
Tyres Front 90/90-21
Rear 120/90-17
Tube type f&r
Front Suspension Telescopic forks Brakes Single disc, 282mm
Disc, 220mm
Rear suspension Mono shock Fuel Capacity 15 L
Performance
Top Speed Fuel Economy
Acceleration
Additional Information

XT600E 1999







Yamaha XV1600A 2000

Yamaha XV250 1999
