XT600E 1999

Engine
Configuration	Air cooled 4-stroke single cylinder SOHC 4 valves. Nicalsil bore.	Gearbox	5 Speed
Bore & Stroke	95x84 mm (3.74x3.31 in)	Ignition	T.C.I. (digital)
Capacity	595 ccm	Charging system	12v
Compression Ratio	8.5:1	Starter	Electric
Max Power	43PS(32,2kW)@6500rpm	Transmission	45/15
Max Torque	4,9kg-m(48,1Nm)@5500rpm	Clutch	Wet multiplate
Fuel	TK Y26PV	Lubrication	Dry sump, SAE 20W40 type SE,  2.5L (2.1 Imp qt, 2.5 US qt)
Chassis
Frame	27.75° caster, 120mm trail	Wheels
Dimensions  Weight  Wheelbase  Length  Seat Height   Ground Clearance	156.0 kg 1,440 mm 2,220 mm 855 mm 230 mm	Tyres	Front 90/90-21 Rear 120/90-17 Tube type f&r
Front Suspension	Telescopic forks	Brakes	Single disc, 282mm Disc, 220mm
Rear suspension	Mono shock	Fuel Capacity	15 L
Performance
Top Speed		Fuel Economy
Acceleration
Additional Information
